Product Series

GX.T&GX.F&GX.S

Thrust spherical plain bearings are particularly suitable for applications with multi-directional, self-aligning movements. GX10T GX12T GX15T GX17T GX20T GX25T GX30T GX35T GX40T GX45T GX50T GX60T GX70T GX80T GX100T GX120T GX140T GX160T GX180T GX200T GX10F GX12F GX15F GX17F GX20F GX25F GX30F GX35F GX40F GX45F GX50F GX60F GX70F GX80F GX100F GX120F GX140F GX160F GX180F GX200F GX10S GX12S GX15S GX17S GX20S GX25S GX30S GX35S GX40S GX45S GX50S GX60S GX70S GX80S GX100S GX120S GX140S GX160S GX180S GX200S

Key words：

bearings

Category ：

Spherical Plain Bearings

E-mail：

kyjen@kyjenbearings.com

E-mail：

richard@kyjenbearings.com

Whatsapp：

+86 18864882435

OTHER PRODUCT

SEND EMAIL TO US

Thrust spherical plain bearings are particularly suitable for applications with multi-directional, self-aligning movements.

They are primarily intended to accommodate axial loads, but also combined (radial and axial) loads.

They can be separated, enabling the rings to be mounted separately.Separable shaft washer and housing washer enable easier mounting.

Bearing Number	Dimensions(mm)
Bearing Number	d	D	B	C
GX10T	10	30	7.5	7
GX12T	12	35	9.5	9.3
GX15T	15	42	11	10.8
GX17T	17	47	11.8	11.2
GX20T	20	55	14.5	13.8
GX25T	25	62	16.5	16.7
GX30T	30	75	19	19
GX35T	35	90	22	20.7
GX40T	40	105	27	21.5
GX45T	45	120	31	25.5
GX50T	50	130	33	30.5
GX60T	60	150	37	34
GX70T	70	160	42	36.5
GX80T	80	180	43.5	38
GX100T	100	210	51	46
GX120T	120	230	53.5	50
GX140T	140	260	61	54
GX160T	160	290	66	58
GX180T	180	320	74	62
GX200T	200	340	80	66
GX10F	10	30	7.5	7
GX12F	12	35	9.5	9.3
GX15F	15	42	11	10.8
GX17F	17	47	11.8	11.2
GX20F	20	55	14.5	13.8
GX25F	25	62	16.5	16.7
GX30F	30	75	19	19
GX35F	35	90	22	20.7
GX40F	40	105	27	21.5
GX45F	45	120	31	25.5
GX50F	50	130	33	30.5
GX60F	60	150	37	34
GX70F	70	160	42	36.5
GX80F	80	180	43.5	38
GX100F	100	210	51	46
GX120F	120	230	53.5	50
GX140F	140	260	61	54
GX160F	160	290	66	58
GX180F	180	320	74	62
GX200F	200	340	80	66
GX10S	10	30	7.5	7
GX12S	12	35	9.5	9.3
GX15S	15	42	11	10.8
GX17S	17	47	11.8	11.2
GX20S	20	55	14.5	13.8
GX25S	25	62	16.5	16.7
GX30S	30	75	19	19
GX35S	35	90	22	20.7
GX40S	40	105	27	21.5
GX45S	45	120	31	25.5
GX50S	50	130	33	30.5
GX60S	60	150	37	34
GX70S	70	160	42	36.5
GX80S	80	180	43.5	38
GX100S	100	210	51	46
GX120S	120	230	53.5	50
GX140S	140	260	61	54
GX160S	160	290	66	58
GX180S	180	320	74	62
GX200S	200	340	80	66
